Compact with high capacity
Compact tri-axle hook lift solution delivering high levels of operational efficiency, low cost of operation and maximum uptime. Enjoy the benefits of a huge 25 tonne payload, 5 tonnes more than the HL211 model.
(1) Reduced weight and bigger payload using leading steels.
(2) Reduced labour per m³ of material transported.
(3) Reduced fuel usage per m³ shuttled.
Flexible with potential
Expandable, modular & customisable.
From bulky → heavy materials
Simply by exchanging hook lift containers
From construction → agriculture
Only with HookLoada
Superior build quality
Renowned for superior specification and build quality, the robust and reliable HL250 model delivers lowest maintenance costs over its impressive lifetime, compared to similar trailers available in the market. Discover the modern 25 tonne hook lift trailer in the video below.
- Low transit hookloader roller height
- Variable height air and hydraulic suspensions available
- Powerful tipping with low oil requirement
- Stable and secure tipping cycles
- Load centre adjusted using the telescopic hook tower
- The most compact design in the tri-axle range
*Container locking design varies according to market.
CommandSteer™ - in-cab control – excellent manoeuvrability in reverse – free steering travelling forwards. Only on rear axle. Watch video >
Load sensing for hydraulic brakes.
Load Sensing Valve (LSV) for air brakes.
Dual air and hydraulic brake system.
Load Sensing Valve (LSV) for hydraulic suspension.
Electronic Power Steering (EPS). Watch video >
Air suspension with height controlling valve (AirLoada™ comes as standard when you buy STR-409). Watch video >
Hydraulic suspension for optimal axle travel. Watch video >
Multi-position sprung drawbar for high comfort at speed.
Hydraulic drawbar for easy levelling and high comfort. Watch video >
Front lift axle - Only with air or hydraulic suspensions. Watch video >
Other tyre brands and tyre sizes available.
Contact us for more information >
Auxiliary hydraulic connections with changeover valve at the rear of the hook lift trailer.
Auxiliary hydraulic connections with electrical changeover valve at the rear of the hook lift.
Auxiliary connections with changeover valve on the hook tower.
Auxiliary connections with electrical changeover valve on the hook tower.
1500mm longer hook stroke.
QuickLoada™ fast tipping and unloading system. Watch video >
Two super-bright LED adjustable rear working lights.
Full length ultra-light aluminium mudguards.
Hard plastic quarter mudguards, front and rear of the hooklift trailer.
Lockable steel toolbox. Various sizes available.
Contact us for more information >
Aluminium side rails to protect the hook lift trailer.
PowerBoosta™ – pair of booster cylinders, increasing tipping and uploading cycle power, removing the requirement for PTO, pump and oil tank. Watch video >
Bolted-on ball towing hitch, Scharmuller type, 80mm diameter.
Swivel towing hitch, Scharmuller type. 50mm diameter eyelet.
Rear towing eyelet mounting plate for VBG rear drawbar.
*Available for selected markets only.
Rear mounted hydraulic brake connection.
Rear mounted light connection 7-pin socket.
Rear real-time video camera with screen display.
|Gross weight (40km/h)||C.D.|
|Tare weight||ca. 6900kg|
|Maximum hooking load||25000kg|
|Maximum tipping load||25000kg|
|Drawbar load||3500kg (4000kg)|
|Sprung suspension capacity||C.D.|
|Main cylinders||2 units|
|Oil requirement||Own hydraulic|
|Minimum draft requirement||190HP|
|Hydraulic pressure required||270 bar|
|Maximum width (standard wheels)||2550mm|
|Standard wheels||560/60 R22,5|
|Connections to tractor||-|
C.D. = Country Dependent
All weights and measurements are subject to hook trailer specification and regional laws. Specification, weights and payload may vary on fast tow models. As we are continually improving our products, technical details, masses and measurements are given as reference values only.
On datasheet below: H = Total height; HH = Hook height; TR = Tower to roller length.
