FlowFeeda

Fully integrated feeding & dosing systems from Stronga

Order now >

Feeding boilers, pyrolysis, gasifiers & biogas plants

Modular, versatile, highly reliable feeder designed to deliver a constant supply of fuel for onward processing in gasifiers, pyrolysis plants, biomass boilers, and dosing in AD biogas plants. Factory-built and tested FlowFeeda equipment is delivered on-time and budget, offering excellent economic results for energy producers.

Get in touch with Stronga today to discuss your fuel feeding or dosing project.

Affordable feed systems

Low purchase cost. FlowFeeda offers a significantly lower capital investment when compared to fixed, shed-based feed systems.

Low labour costs. The powerful combination of high capacity storage with on-demand feeding minimises expensive labour costs.

Low maintenance & ownership costs. Customers enjoy extremely low ownership costs from robust, reliable, wear-resistant feed equipment.

Low energy usage. Energy reduction with low power consumption. Low electrical energy requirement from soft-start system. Lowest kilowatt-electric cost per ton handled.

Designed simplicity

Designed simplicity. Robust, well-proven, dual moving floors with no belts, chains, sprockets and very few moving parts. With simplicity comes reliability and with reliability comes low service and low ownership costs.

Proven to work. FlowFeeda has logged thousands of hours and demonstrated safe and effective operation at all times of year and all temperatures. Stronga feed equipment is proven to deal with the inherent non-uniform characteristics of your material.

Versatile & adaptable

Versatile & adaptable. Multi-purpose dosing and feeding equipment from Stronga is designed for slow moving delivery of wet or dry feedstocks including; biomass, energy crops, alternative fuels and more.

Modular & scalable. Modular, compact design with a range of configuration options. Bespoke feed systems accommodate different layouts and storage capacities with varied throughput.

Controllable capacity

High capacity, plug and play fuel drawing systems from Stronga are arranged to maximise timings between refilling. Stronga specialise in building bespoke, optimised dosing systems designed for your required capacity. Modular walking floor systems can be scaled-up to increase capacities further with easy loading via various roof arrangements.

Success by controlling

The level of controls range from fully automatic, self-feeding to a stand-alone system controlled externally. FlowFeeda is designed for highly varied throughput from very low hourly output to significant, extra high fuel delivery. Integrated self-protection features include thermal protection for the oil and time out protection. Watch the tutorial video below.

Fuel, on-demand

Overall benefits of FlowFeeda

• External weather-proof design, saving valuable internal space.
• Scalable, custom-built capacity to suit your feeding requirements.
• Energy-efficient - low operating hours, even in high duty situations.
• No planning permission / building regulations required (most cases).
• Deals with inherent non-uniform, non-free flowing, fuel characteristics.
• Low capital investment with minimal ownership and maintenance costs.
• Factory-tested, quality-built fuel reception system with Stronga warranty.
• Fully integrated, plug and play system; connect the electrics and go to work.
• Compact, mobile containerised solution located close to point of fuel delivery.
• Deals with many wet or dry feedstocks – alternative fuels, biomass, energy crops.
• Fast on-site procurement; avoid the cost, hassle & uncertainty of in-shed feed systems.

Standard Specifications

60-80m³* fuel storage, reception and feeding system. ISO standard versions available for international shipping.
* Other capacities and layouts available on request
Full length independent moving floors (hydraulically operated); handling even non-free flowing bulk solids. Designed in redundancy with twin bed duality.
Integrated 3-phase electro-hydraulic power pump with oil reservoir; complete with oil tank, cooling system, electric solenoid valves and proximity sensors.
Aluminium air intake cooling louvres. High airflow for natural cooling of the controls and hydraulic equipment.
Powerful, double-acting, floor-operating hydraulic cylinders.
Cross-bracing structural support bars; well-braced, compact, monocoque structure. Easily moveable between sites.
Full height material sight gauges.
Electrical intake isolation point. Easy external connection of electrical supply and safe power isolation.

Optional Equipment

FFL-101
Step ladder and access platform with self-closing gate and padlock.
FFL-102
Hydraulic folding roof with hand or hydraulic* pump operation; complete independent hydraulic circuit.
*Optional 240V electro-hydraulic pump, complete with open / close control
FFL-103
Smart controls* with manual & automatic modes. Volt-free signals for on-demand feed. Complete with thermal self-protection.
*Available to the client’s specification
FFL-104
Legs of various heights available, bolted on to the underside of the chassis. Optimised discharge height for augers and conveyors.
FFL-105
High capacity cross feed trough auger with shaped in-feed housing to prevent material flooding.
FFL-106
Client-supplied cross conveyor; integrated weatherproof enclosure.
FFL-107
Anti-corrosion stainless steel lining, inside FlowFeeda.
*Other polymer coatings available on request
MODEL FF60FF80FF ISO***
Gross weight*5500kg8500kg9500kg
Overall length8500mm10865mm12200mm
Overall width3120mm3120mm2440mm
Overall height (excluding legs)2800mm2800mm2900mm
Loading capacity**60m³80m³76m³
Floor rear feed aperture heightTo suit clients requirementsTo suit clients requirementsTo suit clients requirements
3 phase electro-hydraulic power unitStandardStandardStandard
Proximity switches for floor control24V or 240V24V or 240V24V or 240V
Floor speed flow valveStandardStandardStandard
Sight gaugesStandardStandardStandard
E-stop safety shutdownStandardStandardStandard
Electrical intake isolation pointStandardStandardStandard

*Depending on equipment fitted.

**Loading capacity depends on the bulk density of the material.

***Other FF ISO capacities available. Contact us for more information.

All weights and measurements are subject to specification and regional laws. As we are continually improving our products, technical details, masses and measurements are given as reference values only.

Please note – Datasheet below showing FF60 model is just for show. Each FlowFeeda is custom-built to the unique requirements of the client.
