DumpLoada DL1200

Our biggest tandem-axle tipper. 25% more capacity than DL1000.

Get ready to work

with DumpLoada DL1200

Get ready to work with the high capacity, heavy-duty DumpLoada DL1200 earth moving tipper trailer. Designed for the longest possible service life, reliability and durability; hauling is easier, safer and more efficient than ever before using the DL1200 tipper trailer. With 15m³ of standard transport capacity; the DL1200 model offers the largest carrying capacity from a tandem-axle tipper.

15m³ standard transport capacity

The best tipper just got better

Is that even possible?

Biggest tandem-axle tipper

Available in the Stronga range

Loaded with exclusive features, high performance components and stunning technical advantages, these hard-working heavy-duty tipper trailers deliver more output on a regular basis. The DL1200 earth moving tipper trailer is capable of moving more tonnes per hour that other tandem axle tippers in the market, giving maximum effort and output in all conditions. The 2nd largest tipper in the Stronga range has a bigger payload to thrive in your heavy material application.

Haul with confidence

Each Stronga earth moving tipper trailer is built for tough conditions travelling at speeds of up to 40 kilometres per hour on the road. With sure-footed traction, maximum ground contact and a wide-opening hydraulic tailgate, the DL1200 tipper trailer is ideal for high output, heavy material applications such as road building projects, mass excavation, mining and quarrying.

Standard Specifications

BPW commercial axle, 410x180 brake axles, 150x150mm square beam, 10 stud.
24t parabolic sprung suspension. 1525mm distance between axles.
Multi-position sprung drawbar for high comfort at speed.
445/65 R22,5 radial tyres. Load rating per tyre:

7000 kg @ 105 km/h
Hard plastic quarter mudguards, front and rear of the dump loader trailer.
2 x rear rubber mud-flaps.
Multi-position rear tipper trailer removable round bumper.
Single top-hung rear door with hydraulic flip back.
Brackets with lock for the rear door in the front of the earth moving tipper trailer box.
3 position plate for bolting towing eyelet.
Swivel towing hitch. STR type. 50mm diameter eyelet.
HARDOX 450 steel. 10mm tipper trailer floor. 8mm tipper trailer sides.
12 V electric system. Sealed loom. All lights super-bright LED.
Cable-type hand brake.
Suspended drawbar shoe with stowage point.

Optional Equipment

STR-302
Load sensing for hydraulic brakes.
STR-304
Load Sensing Valve (LSV) for air brakes.
STR-305
Dual air and hydraulic brake system.
STR-307
Automatic slack adjusters.
STR-308
Load Sensing Valve (LSV) for hydraulic suspension.
STR-505
Bolted-on ball towing hitch, Scharmuller type, 80mm diameter.
STR-506
Swivel towing hitch, Scharmuller type. 50mm diameter eyelet.
STR-409
Air suspension with height controlling valve.
STR-410
Hydraulic suspension for optimum axle travel. Watch video >
STR-411
Front lift axle - Only with air or hydraulic suspensions. Watch video >
STR-508
Hydraulic drawbar for easy tipper trailer levelling and high comfort. Watch video >
STR-707
Electronic Power Steering (EPS) for excellent efficiency and safety. Watch video >
STR-802
Other tyre brands and tyre sizes available.
Contact us for more information >
STR-1000
Lockable steel toolbox. Various sizes available.
Contact us for more information >
STR-1001
Aluminium tipper trailer side protection rails.
STR-1037
Two super-bright LED rear working lights.
STR-1002
Rear towing eyelet mounting plate for VBG rear drawbar.
STR-1038
Rear mounted hydraulic brake connection.
STR-1039
Rear mounted light connection 7-pin socket.
STR-1056
Rear real-time video camera with screen display.
Model DL1200
Gross weight 26000kg
Tare weight ca. 6000kg
Maximum Payload 20000kg
Drawbar load 3500kg (4000kg*)
Sprung suspension capacity 24000kg
Standard transport capacity 15m³
Lift capacity of step 1 at 180 bar 38,4 tonnes
Oil requirement 29,4 litres
Minimum draft requirement 92kW (125HP)
Hitch height 510-550-590mm
Bottom thickness 10 mm HARDOX 450
Side thickness 8 mm HARDOX 450
Body height inside 1200mm
Body length inside 5150mm
Total length 6750mm
Total height 2650mm
Total height at 65˚ 6500mm
Maximum width (standard wheels) 2550mm
Standard wheels 445/65 R22,5
Colour Yellow
Speed 40km/h

All weights and measurements are subject to earth moving tipper trailer specification and regional laws. Specification, weights and payload may vary on fast tow models. As we are continually improving our products, technical details, masses and measurements are given as reference values only.
