BulkLoada BL20-16

Compact tandem-axle vegetable trailer.

Compact tandem-axle vegetable trailer available at stunning value for money. BL20-16 is the perfect transport solution for contractors wanting a reliable, well-proven, mid-capacity vegetable harvest trailer. With 20m³ standard transport capacity, the BL20-16 sets the standard when compared to similar products in the market.

5 key features of BL20-16:

(1) Big flotation tyres - Michelin Cargo XBIB 560/60 R22,5 – minimal ground pressure to protect your fields.
(2) LowLina™ body on a heavy-duty chassis - eliminating spillages of bulky materials on-road or in-yard.
(3) Flexible across arable, vegetable and silage – finish one harvest and then move on to the next.
(4) SmoothSida™ body – no weld seams ensure that your crop is fully protected from damage.
(5) High strength, class-leading BPW axle with high capacity 21 tonne suspension system.

Well-proven & reliable

Mid-capacity vegetable trailer.

You’re always in control

Heavy-duty BPW axles on tandem springs ensure a smooth ride on all terrains, whether partially or fully loaded with root crops. To compensate for wear and tear when loading bulky materials, the BL20-16 model features heavy-gauge sides, strengthening channels and a heavy-duty steel floor. What’s more, the long-reach chromed cylinder delivers a big tipping angle to make efficient use of your yard space.

Standard Specifications

BPW axle, 410x180 brake axles, 120x120mm square beam, 10 stud.
Bogie suspension.
Shockproof rubber-mount drawbar.
WABCO air brakes on all wheels (excl. Load Sensing Valve).
560/60 R22,5 Michelin Cargo XBIB radial tyres. 10 stud heavy-duty wheels.
Hard plastic quarter mudguards, front and rear.
Large front viewing window.
Hydraulic support leg with hand pump.
Hydraulic rear door with safety valves.
One-piece body sides.
Rubber seal between door and body.
PolyGlider™ grain chute with easy opening and closing motion.
Rear towing eyelet – STR type.
12 V electric system. Sealed loom. All lights super-bright LED.
LED working lights inside the body.
3 position plate for bolting towing eyelet.
Swivel towing hitch. STR type. 50mm diameter eyelet.

Optional Equipment

STR-210
BPW high speed commercial axle, 410x180 brake axles, 150x150 - 16mm square beam, 10 stud.
STR-211
BPW auto-centring free steering rear axle, 420x180 brake axles, 150x150 - 16mm square beam, 10 stud, 2150mm track.
STR-213
Hydraulic steering system.
STR-300
Hydraulic brakes on all wheels.
STR-302
Load sensing for hydraulic brakes.
STR-304
Load Sensing Valve (LSV) for air brakes.
STR-404
24t parabolic sprung suspension, 1525mm distance between axles.
STR-505
Bolted-on ball towing hitch, Scharmuller type, 80mm diameter.
STR-508
Hydraulic drawbar for easy levelling and high comfort. Watch video >
STR-700
Auxiliary hydraulic connections with changeover valve at the rear of the trailer.
STR-716
Hydraulic folding rear bumper.
STR-802
Other tyre brands and tyre sizes available.
Contact us for more information >
STR-1038
LED rear working lights.
STR-1039
LED rear flashing light.
STR-1047
Roll sheet cover rack.
STR-1048
Special, ultra-tough plastic lining the top of the body.
STR-1049
LED lights at the top of the rear door.
STR-1050
Plexiglass viewing window.
STR-1052
Safety access platform.
STR-1053
2750mm wide metal mudguards.
STR-1054
Signal light at the front of the frame so you can see when your steering system is in the middle.
STR-1055
Working lights automatically switch on automatically during body tipping.
STR-1056
Rear real-time video camera with screen display.
Model BL20-16
Gross weight 22000kg
Tare weight ca. 5000kg
Maximum Payload 17000kg
Drawbar load 3500kg (4000kg*)
Standard transport capacity 20m³
Oil requirement 40 litres
Minimum draft requirement 100HP
Hitch height 510-550-590mm
Bottom steel type Hardox 450
Body height inside 1400mm
Body length inside 6265mm
Total length 8335mm
Total height 2925mm
Maximum width (standard wheels) 2550mm
Standard wheels 560/60 R22,5
Colour Yellow
Speed 40km/h
Suspension capacity 21000kg (Bogie)

All weights and measurements are subject to vegetable trailer specification and regional laws. Specification, weights and payload may vary on fast tow models. As we are continually improving our products, technical details, masses and measurements are given as reference values only.
